Ubiquiti PowerBeam M5 400 (PBE-M5-400)

The Ubiquiti PowerBeam M5 400 (PBE-M5-400) is a high-performance outdoor wireless bridge designed for long-range point-to-point connectivity. Operating on the 5 GHz frequency band, it combines a powerful integrated antenna with advanced airMAX technology to deliver stable, high-throughput links over extended distances. With its rugged UV-stabilized construction, excellent wind resistance, and efficient passive PoE power design, the PowerBeam M5 400 is ideal for internet service providers, enterprise backhaul networks, and remote connectivity applications.

Product Features

Long-Range Wireless Performance

Delivers reliable point-to-point connectivity with up to 26 dBm transmit power and high-gain antenna performance for extended coverage.

Integrated High-Gain Antenna

Features a 25 dBi antenna gain with dual linear polarization, ensuring strong signal strength and improved link stability.

airMAX Technology

Optimized for outdoor wireless bridging with reduced latency, improved throughput, and efficient spectrum utilization.

Rugged Outdoor Design

Constructed with UV-stabilized plastic and tested against extreme environmental conditions including wind, rain, and temperature fluctuations.

Efficient PoE Power System

Powered via passive PoE with low power consumption of 8W, enabling simple deployment in remote locations.

Product Specifications

• Dimensions: 420 x 420 x 275 mm (16.5 x 16.5 x 10.8″)
• Weight: 1.8 kg (4.8 lb)
• Enclosure Material: UV-stabilized plastic
• Mounting: Pole mount kit included
• Wind Survivability: 200 km/h (125 mph)
• Wind Loading: 342.5 N @ 200 km/h (77 lbf @ 125 mph)
• Networking Interface: 1 GbE RJ45 port
• Power Method: Passive PoE 2-pair (4,5+; 7,8 return)
• Power Supply: 24V, 0.5A Gigabit PoE adapter (included)
• Supported Voltage Range: 20–27V DC
• Max. Power Consumption: 8W
• Max. TX Power: 26 dBm
• Antenna Gain: 25 dBi
• System Gain: 22 dBi
• Polarization: Dual linear
• Channel Sizes: 5/8/10/20/30/40 MHz
• ESD/EMP Protection: Air/contact ±24 kV
• LED Indicators: Power, LAN, WLAN (4 LEDs)
• Signal Strength LEDs: Software-adjustable RSSI levels
• Operating Frequency (Worldwide): 5170–5875 MHz
• Operating Frequency (US/CA): 5725–5850 MHz
• Ambient Operating Temperature: -40 to 70°C (-40 to 158°F)
• Ambient Operating Humidity: 5–95% non-condensing
• Compliance: NDAA Compliant, CE, FCC, IC certified
• Environmental Tests: Salt fog (IEC 68-2-11), vibration (IEC 68-2-6), temperature shock (IEC 68-2-14), UV exposure (IEC 68-2-5), wind-driven rain (ETS 300 019-1-4)
