Ubiquiti airMAX NanoStation 5AC Loco Compact (Loco5ac)
The Ubiquiti airMAX NanoStation 5AC Loco Compact (Loco5ac) is a lightweight and cost-effective outdoor wireless radio designed for efficient point-to-point and point-to-multipoint connectivity in the 5 GHz band. Powered by airMAX ac technology, it delivers reliable throughput, low latency, and excellent spectral efficiency for small to medium-range deployments. Its compact design, Gigabit Ethernet connectivity, and durable UV-stabilized enclosure make it an ideal solution for wireless ISPs, home network extensions, and outdoor bridging applications.
Product Features
Compact and Lightweight Design
Engineered for easy deployment, the slim and lightweight form factor simplifies installation while maintaining strong performance in outdoor environments.
High-Speed 5 GHz Connectivity
Operates in the 5 GHz spectrum with airMAX ac technology, ensuring faster data transmission, reduced interference, and improved link stability.
Gigabit Ethernet Interface
Features a single GbE RJ45 port, providing high-speed wired connectivity for seamless integration into modern networks.
Efficient Passive PoE Power
Powered via passive PoE, allowing flexible installations with minimal cabling requirements, ideal for remote or elevated mounting locations.
Integrated Directional Antenna
Equipped with a 13 dBi antenna and optimized beamwidth for stable connections and improved signal focus over distance.
Built-In Management Radio
Includes a dedicated 2.4 GHz management radio for convenient configuration and monitoring without interrupting the main wireless link.
Rugged Outdoor Build
Constructed with UV-stabilized plastic and designed to withstand harsh environmental conditions, ensuring long-term durability.
Product Specifications
- Dimensions: 179 x 77.5 x 59.1 mm (7.1 x 3.1 x 2.3 inches)
- Weight: 180 g (6.4 oz)
- Enclosure Material: UV-stabilized plastic
- Mounting: Pole mounting kit (included)
- Networking Interface: (1) GbE RJ45 port
- Power Method: Passive PoE 2-pair (4, 5+; 7, 8 return)
- Power Supply: 24V, 0.3A gigabit PoE supply (not included)
- Supported Voltage Range: 22–27V DC
- Maximum Power Consumption: 7W
- LED Indicators: Power, Ethernet, (4) signal strength LEDs
- Operating Temperature: -40 to 70°C (-40 to 158°F)
- Operating Humidity: 5 to 95% non-condensing
- Certifications: CE, FCC, IC
- NDAA Compliant: Yes
- Frequency Band: 5 GHz
- Operating Frequency (Worldwide): 5150–5875 MHz
- Operating Frequency (USA U-NII-1): 5150–5250 MHz
- Operating Frequency (USA U-NII-2A): 5250–5350 MHz
- Operating Frequency (USA U-NII-2C): 5240–5725 MHz
- Operating Frequency (USA U-NII-3): 5725–5850 MHz
- Management Radio Frequency (Worldwide): 2412–2472 MHz
- Management Radio Frequency (US/CA): 2412–2462 MHz
- Antenna Gain: 13 dBi
- Channel Bandwidths: 10/20/30/40/50/60/80 MHz
- Cross-Polarization Isolation: 20 dB minimum
- Max VSWR: 1.8:1
- Beamwidth: 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
- Polarization: Dual linear
