Ubiquiti airMAX NanoStation 5AC (NS-5AC)

The Ubiquiti airMAX NanoStation 5AC (NS-5AC) is a high-performance outdoor wireless radio built for long-range point-to-point and point-to-multipoint connectivity using advanced 802.11ac technology. Designed for modern wireless networking, it delivers faster throughput, improved spectral efficiency, and reduced latency compared to legacy models. With dual Gigabit Ethernet ports, flexible PoE support, and a rugged UV-resistant enclosure, the NS-5AC is ideal for ISPs, enterprise backhaul, and high-capacity outdoor deployments in challenging environments.

Product Features

Advanced 5 GHz 802.11ac Performance

Utilizes the 5 GHz spectrum with 802.11ac technology to deliver higher speeds, lower latency, and improved network efficiency.

Dual Gigabit Ethernet Ports

Equipped with two GbE RJ45 ports for high-speed data transfer and flexible network configurations, including bridging and device passthrough.

Flexible PoE Power Options

Supports both 24V passive PoE and 48V PoE (Alternative A), providing greater deployment flexibility and compatibility with different power setups.

Integrated High-Gain Antenna

Features a 16 dBi antenna with optimized beamwidth for strong signal performance and reliable long-distance connectivity.

Built-In Management Radio

Includes a dedicated 2.4 GHz management radio for easier device setup, monitoring, and maintenance without interrupting the main link.

Rugged Outdoor Design

Constructed with UV-resistant plastic and engineered to operate in extreme temperatures, ensuring durability in harsh outdoor conditions.

Enhanced Surge Protection

Provides ESD and EMP protection up to ±24 kV, safeguarding the device against electrical surges and environmental interference.

Product Specifications

• Dimensions (Without Mount): 257 x 84 x 41 mm (10.1 x 3.3 x 1.6 inches)
• Dimensions (With Mount): 257 x 84 x 30 mm (10.1 x 3.3 x 1.2 inches)
• Weight: 233 g (8.2 oz)
• Enclosure Material: UV-resistant plastic
• Mounting: Pole and wall mounting kits (included)
• Networking Interface: (2) GbE RJ45 ports
• Power Method: PoE Alternative A (pairs 1, 2+; 3, 6 return), Passive PoE 2-pair (4, 5+; 7, 8 return)
• Power Supply: 24V, 0.5A gigabit PoE adapter (included)
• Supported Voltage Range: 44–54V DC, 22–27V DC
• Maximum Power Consumption: 9W
• ESD/EMP Protection: Air/contact ±24 kV
• LED Indicators: Power, Ethernet, (4) signal strength LEDs
• Operating Temperature: -40 to 70°C (-40 to 158°F)
• Operating Humidity: 5 to 95% non-condensing
• Certifications: CE, FCC, IC
• NDAA Compliant: Yes
• Frequency Band: 5 GHz
• Operating Frequency (Worldwide): 5150–5875 MHz
• Operating Frequency (USA U-NII-1): 5150–5250 MHz
• Operating Frequency (USA U-NII-2A): 5250–5350 MHz
• Operating Frequency (USA U-NII-2C): 5240–5725 MHz
• Operating Frequency (USA U-NII-3): 5725–5850 MHz
• Management Radio Frequency (Worldwide): 2412–2472 MHz
• Management Radio Frequency (US/CA): 2412–2462 MHz
• Antenna Gain: 16 dBi
• Channel Bandwidths: 10/20/30/40/50/60/80 MHz
• Cross-Polarization Isolation: 20 dB minimum
• Max VSWR: 1.6:1
• Beamwidth: 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
• Polarization: Dual linear
