Ubiquiti airMAX 5GHz LiteAP AC Access Point (LAP-120)
The Ubiquiti airMAX 5GHz LiteAP AC Access Point (LAP-120) is a compact, high-performance wireless radio designed for point-to-multipoint broadband deployments in the 5 GHz spectrum. Featuring integrated antenna technology, airMAX AC protocol support, and efficient power consumption, the LiteAP AC delivers reliable connectivity, improved throughput, and scalable network coverage. Its lightweight yet durable design makes it ideal for WISPs, rural connectivity, and outdoor enterprise networking applications requiring stable and cost-effective wireless distribution.
Product Features
Integrated High-Gain Antenna
The LiteAP AC comes with a built-in 16 dBi antenna, eliminating the need for external antennas while ensuring optimized signal coverage and simplified installation.
airMAX AC Technology
Powered by advanced airMAX AC protocol, the device enhances network efficiency, reduces latency, and improves overall throughput for point-to-multipoint deployments.
Compact and Lightweight Design
With a slim form factor and low weight, the LAP-120 is easy to mount and deploy, making it ideal for quick installations in various outdoor environments.
Reliable Outdoor Performance
Engineered for durability, the device withstands extreme temperatures, high winds, and harsh environmental conditions, ensuring consistent operation in outdoor deployments.
Efficient Power Consumption
Operating at a maximum of 8W, the LiteAP AC delivers energy-efficient performance using Passive PoE, reducing operational costs.
Gigabit Ethernet Connectivity
Equipped with a GbE RJ45 port, the access point supports high-speed wired connections for improved data throughput and network performance.
Product Specifications
- Model: LAP-120
- Networking Interface: (1) GbE RJ45 port
- Power Method: Passive PoE 2-pair (4, 5+; 7, 8 return)
- Power Supply: 24V, 0.5A Gigabit PoE Adapter (Included)
- Supported Voltage Range: 20 to 27V DC
- Max Power Consumption: 8W
- Antenna Gain: 16 dBi
- Dimensions: 452.3 x 78.7 x 54.4 mm
- Weight: 420 g
- Wind Survivability: 200 km/h (125 mph)
- Wind Loading: 77 N at 200 km/h
- ESD/EMP Protection: Air/contact ±24 kV
- Operating Temperature: -40 to 70 degrees C
- Operating Humidity: 5 to 95 percent noncondensing
- Certifications: CE, FCC, IC
- Frequency Range (Worldwide): 5150 to 5875 MHz
- NDAA Compliant: Yes
