MSI GeForce RTX 5060 Ti 16GB GAMING TRIO OC (912V532-030)

The MSI GeForce RTX 5060 Ti 16GB GAMING TRIO OC (912V532-030) is a high-performance graphics card built on the NVIDIA Blackwell architecture, designed for demanding gaming, advanced ray tracing, and AI-accelerated creative workloads. Featuring 16GB of ultra-fast GDDR7 memory, a factory-overclocked GPU, and MSI’s premium TRI FROZR 4 triple-fan cooling system, this card delivers exceptional performance, thermal efficiency, and stability for high-resolution gaming and professional applications.

Product Features

NVIDIA Blackwell Architecture Performance

Powered by the NVIDIA GeForce RTX 5060 Ti GPU with 4,608 CUDA cores, delivering next-generation rendering performance, improved efficiency, and enhanced AI-driven graphics capabilities.

16GB GDDR7 High-Speed Memory

Equipped with 16GB of GDDR7 memory on a 128-bit interface, providing high bandwidth and smooth performance for modern AAA gaming, 3D rendering, and AI workloads.

Factory Overclocked Boost Performance

Delivers a boost clock of up to 2,647 MHz, with Extreme Performance mode reaching up to 2,662 MHz via MSI Center for enhanced gaming responsiveness.

TRI FROZR 4 Triple-Fan Cooling System

MSI’s premium TRI FROZR 4 cooling solution uses three STORMFORCE fans and an advanced heatsink design with a nickel-plated copper baseplate to ensure efficient heat dissipation under heavy load.

DLSS 4 and AI-Enhanced Gaming

Supports DLSS 4 with Multi Frame Generation and advanced ray tracing cores, enabling smoother gameplay, higher frame rates, and improved visual realism.

Zero Frozr Silent Technology

Fans automatically stop during low-load operation, ensuring completely silent performance during light usage and everyday tasks.

PCIe 5.0 High-Speed Interface

Built with PCIe Gen 5 x16 connectivity (electrically operating at x8), ensuring fast data transfer between GPU and system for optimal performance.

Advanced Display Connectivity

Supports up to four displays with three DisplayPort 2.1b outputs and one HDMI 2.1b port, enabling resolutions up to 8K at 120Hz with DSC support and ultra-high refresh rate output.

Reinforced Structural Design

Features a durable metal backplate with airflow vents and thermal padding to improve cooling efficiency and overall structural rigidity.

Product Specifications

• Model Name: MSI GeForce RTX 5060 Ti 16GB GAMING TRIO OC
• GPU Architecture: NVIDIA Blackwell
• CUDA Cores: 4,608
• Memory: 16GB GDDR7
• Memory Bus: 128-bit
• Memory Speed: 28 Gbps
• Memory Bandwidth: 448 GB/s
• Boost Clock: 2,647 MHz
• Extreme Performance Clock: Up to 2,662 MHz (MSI Center)
• Power Consumption: 180W
• Recommended PSU: 600W to 650W
• Power Connector: 1 x 16-pin (ATX 3.1 recommended)
• Display Outputs: 3 x DisplayPort 2.1b, 1 x HDMI 2.1b
• Maximum Resolution: Up to 8K (7680 x 4320) with DSC support
• PCIe Interface: PCIe 5.0 x16 (x8 electrical)
• Cooling System: TRI FROZR 4 Triple-Fan (STORMFORCE fans)
• Card Dimensions: 300 x 125 x 44 mm
• Weight: 844 g (card) / 1,384 g (package)
