MikroTik Cloud Core Router 2116-12G-4S+ (CCR2116-12G-4S+)

The MikroTik CCR2116-12G-4S+ is a next-generation, high-performance router built for demanding ISP, enterprise, and data center environments. Featuring a 16-core ARMv8 Alpine v2 CPU running at 2 GHz, this router delivers unparalleled single-core and multi-core performance, doubling the throughput of previous CCR models. With 12 Gigabit Ethernet ports and four 10G SFP+ ports, the CCR2116-12G-4S+ provides robust connectivity for complex networks, while its dual redundant power supplies, M.2 PCIe slot, and RouterOS v7 Level 6 ensure reliability, scalability, and advanced routing capabilities. Designed for massive BGP, heavy firewall processing, and Layer 3 hardware offloading, this router combines raw power with cutting-edge network efficiency.

Product Features

16-Core ARM CPU

Powered by a 16-core Amazon Annapurna Labs AL73400 CPU running at 2 GHz with 16 threads, the router achieves unmatched processing performance for demanding routing and firewall tasks.

High-Speed 10G Connectivity

Four dedicated SFP+ ports support 10G fiber connections, each with a full-duplex line to the Marvell Aldrin switch chip, enabling bottleneck-free network performance.

Gigabit Ethernet Ports

Twelve Gigabit Ethernet ports are managed through a Marvell switch chip, with an additional CPU-connected port for dedicated management.

Dual Redundant Power Supplies

Equipped with two AC inputs and dual PSU slots, the CCR2116-12G-4S+ ensures uninterrupted operation in critical environments.

M.2 PCIe Slot

A built-in M.2 slot allows for high-speed storage expansion or additional peripheral options to enhance performance and network functionality.

Advanced Monitoring and Controls

Includes CPU and PCB temperature monitoring, voltage monitoring, and a mode button for real-time diagnostics and operational control.

Industrial Reliability

Tested for operation in temperatures from -20°C to 60°C with an MTBF of approximately 200,000 hours, providing durable and long-lasting network performance.

Product Specifications

• Product Code: CCR2116-12G-4S+
• Architecture: ARM 64-bit
• CPU: AL73400, 16 cores, 2.0 GHz, 16 threads
• Switch Chip Model: Marvell 98DX3255
• RAM: 16 GB
• Storage: 128 MB NAND
• RouterOS License: Level 6
• Operating System: RouterOS v7
• Dimensions: 443 x 199 x 44 mm
• Tested Ambient Temperature: -20°C to 60°C
• MTBF: ~200,000 hours at 25°C
• AC Inputs: 2 (100–240V, 47–63 Hz)
• PSU Slots: 2
• Max Power Consumption: 83 W (60 W without attachments)
• Cooling Type: 4 fans
• Gigabit Ethernet Ports: 13
• SFP+ Ports: 4
• Serial Console Port: RJ45
• M.2 Slots: 1
• CPU & PCB Temperature Monitor: Yes
• Voltage Monitor: Yes
• Mode Button: Yes
• Certifications: CE, EAC, ROHS
