Lightwave Multimode Duplex Fiber Patch Cord LSZH SC UPC to SC UPC OM2 3M (LW-PC-SCU-SCU-DX-MM-3M)

The Lightwave LW-PC-SCU-SCU-DX-MM-3M is a high-performance 3-meter multimode duplex fiber patch cord designed for reliable, high-speed data transmission in data centers, enterprise LANs, and network environments. Built with OM2 50/125 µm multimode fiber and SC/UPC connectors on both ends, this patch cord delivers low insertion loss and stable signal performance over short to medium distances. Its LSZH jacket enhances safety for indoor installations, while the duplex zipcord design supports simultaneous bidirectional communication, making it ideal for connecting switches, servers, and network equipment in high-density setups.

Product Features

High-Precision SC/UPC Connectors

Ultra Physical Contact connectors ensure accurate alignment, reducing signal loss and maintaining consistent network performance.

Duplex Multimode Fiber Configuration

Dual-fiber zipcord design supports simultaneous transmit and receive operations for efficient data communication.

Optimized for Short-Distance Networking

OM2 multimode fiber is ideal for LANs and data centers, supporting high-speed data transmission with reliable performance.

LSZH Safety Jacket

Low Smoke Zero Halogen jacket minimizes toxic emissions and smoke, ensuring safe use in enclosed and sensitive environments.

Durable and Flexible Design

Equipped with zirconia ceramic ferrules, pull-proof boots, and bend-insensitive construction for long-term reliability and easy routing.

Product Specifications

• Model: LW-PC-SCU-SCU-DX-MM-3M
• Connector Type: SC/UPC to SC/UPC
• Fiber Type: Multimode OM2 (50/125 µm)
• Cable Length: 3 meters
• Cable Construction: Duplex (DX) zipcord
• Jacket Material: LSZH (Low Smoke Zero Halogen), aqua color
• Cable Diameter: 3.0 mm
• Insertion Loss: ≤0.3 dB per connector
• Return Loss: ≥20 dB
• Operating Wavelengths: 850 nm and 1300 nm
• Modal Bandwidth: 500 MHz·km at 850 nm
• Transmission Distance: Up to 550 meters at 1 Gbps, up to 82 meters at 10 Gbps
• Ferrule Material: Zirconia ceramic
• Tensile Strength: Up to 100 N during installation
• Minimum Bend Radius: Designed for tight routing with minimal signal loss
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +80°C
• Compliance: RoHS, IEC 60793-2-10, TIA/EIA 492AAAB
