Hikvision DS-2CD1023G0E-I 2MP Fixed Bullet Network Camera

The Hikvision DS-2CD1023G0E-I is a 2MP fixed bullet IP camera designed for reliable indoor and outdoor surveillance. Featuring high-resolution imaging, EXIR 2.0 infrared technology, and efficient H.265+ compression, it provides clear video even in low-light conditions. Its IP67-rated weather-resistant design ensures durability, while digital WDR technology maintains image clarity against strong backlight. Ideal for homes, offices, and retail environments, this camera offers advanced monitoring with easy installation via Power over Ethernet (PoE).

Product Features

High-Resolution Imaging

The camera uses a 1/2.7″ progressive scan CMOS sensor to capture sharp 1920 × 1080 video for accurate monitoring of critical areas.

EXIR 2.0 Infrared Technology

Equipped with an IR illuminator with up to 30 meters range and 850 nm wavelength, this camera ensures clear night vision with minimal reflection and glare.

IP67 Weather-Resistant Design

Durable construction protects the camera from dust and water, making it suitable for both indoor and outdoor installation.

Efficient H.265+ Video Compression

Supports H.265+, H.265, H.264+, and H.264 codecs to reduce bandwidth and storage requirements without compromising video quality.

Digital Wide Dynamic Range (DWDR)

Enhances image clarity in challenging lighting conditions by balancing strong backlight and shadows for consistent, high-quality video.

Flexible Lens Options

Available with 2.8 mm or 4 mm fixed focal lenses, offering horizontal FOVs of 112.1° and 90.2° respectively, to cover wide or narrow monitoring areas.

Network and Security

Supports up to 32 users with three access levels, secure password protection, IP address filtering, and standard protocols including TCP/IP, HTTPS, and IPv6.

Event Management

Detects motion, video tampering, and exceptions, with alert notifications sent via email or uploaded to FTP for proactive surveillance.

Product Specifications

• Image Sensor: 1/2.7″ Progressive Scan CMOS
• Max. Resolution: 1920 × 1080
• Min. Illumination: Color: 0.01 Lux @ F2.0 (AGC ON), B/W: 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter
• Pan/Tilt/Rotate: 0°–360° / 0°–180° / 0°–360°
• Lens Type: Fixed focal lens (2.8 mm or 4 mm)
• Field of View (FOV): 2.8 mm: H 112.1°, V 60.0°, D 132.2°; 4 mm: H 90.2°, V 48.6°, D 107.6°
• Aperture: F2.0
• IR Range: Up to 30 m, Smart IR
• IR Wavelength: 850 nm
• Video Compression: H.265+/H.265/H.264+/H.264; Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate: 32 Kbps – 8 Mbps
• Region of Interest (ROI): 1 fixed region for main stream
• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive
• Simultaneous Live View: Up to 6 channels
• Protocols Supported: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
• User/Host Levels: Up to 32 users; administrator, operator, user
• Power Supply: 12 VDC ± 25%, 0.4 A, max 5 W; PoE 802.3af Class 3, max 6.5 W
• Dimensions: 177.6 mm × 66.2 mm × 67.8 mm (7.0″ × 2.6″ × 2.7″)
• Weight: 270 g (0.6 lb); With package: 490 g (1.1 lb)
• Operating Temperature: -30 °C to 60 °C (-22 °F to 140 °F), humidity ≤95%
• Certifications: FCC SDoC, CE-EMC, RCM, IC VoC, KC, UL, CB, CE-LVD, BIS
• Environmental Compliance: CE-RoHS, WEEE, REACH
• Protection: IP67
