Fanvil H3 Hotel IP Phone

The Fanvil H3 is a cost-effective hotel IP phone specifically designed for hospitality environments such as guest rooms, lobbies, and reception areas. Featuring a sleek, screenless design with a customizable printed faceplate, it allows hotels to provide branded, user-friendly communication while supporting high-speed charging for guest devices. With dual Ethernet ports, PoE support, and programmable soft keys tailored for hotel services, the H3 combines reliability, functionality, and affordability for modern hospitality operations.

Product Features

High-Definition Audio

Delivers HD voice quality through a full-duplex hands-free speakerphone and incorporates acoustic echo cancellation (AEC) for crystal-clear communication.

Programmable Keys

Equipped with 6 programmable soft keys that can be customized for essential hotel services such as housekeeping, room service, or the front desk, enhancing guest convenience and staff efficiency.

USB Charging

Includes a built-in USB-A port to charge guest mobile devices directly from the phone, reducing clutter and improving in-room guest experience.

Networking Options

Features dual 10/100 Mbps Ethernet ports for reliable wired connectivity. The H3 is PoE-enabled, allowing both data and power over a single cable for simplified installation.

SIP Line Support

Supports 1 or 2 SIP lines depending on configuration, making it flexible for small to medium hospitality setups.

Broad Compatibility

Compatible with major VoIP platforms including 3CX, Broadsoft, Asterisk, and Elastix, ensuring seamless integration with existing hotel communication infrastructure.

Variants and Upgrades

• H3W: Includes built-in 2.4G Wi-Fi for locations where network cabling is difficult.
• H5: Offers a 3.5-inch color display (480×320) and additional video decoding capabilities for enhanced in-room communication.

Product Specifications

• Display: None (customizable printed faceplate)
• SIP Lines: 1 or 2 depending on configuration
• Networking: Dual 10/100 Mbps Ethernet ports (wired); H3W includes 2.4G Wi-Fi
• Audio Codecs: H3 – G.722, G.711, G.729; H3W – G.722, Opus, G.711; H5 – G.722, Opus, G.711
• USB Port: 1 x USB-A for device charging
• Programmable Keys: 6 DSS keys for hotel services
• Audio Features: Full-duplex hands-free speakerphone with Acoustic Echo Cancellation (AEC) and Packet Loss Concealment (PLC)
• Power Supply: PoE (802.3af Class 2) or optional 5V/2A DC adapter
• Installation: Desktop or wall-mounted (wall bracket sold separately)
• Physical Dimensions: 151.7 × 193.2 × 131.7 mm
• Security & Protocols: VPN support (L2TP/OpenVPN), 802.1x network access control, SIP over TLS/SRTP
• Platform Compatibility: 3CX, Asterisk, Broadsoft, Metaswitch
