Sollatek Inverter 300 VA

The Sollatek Inverter 300 VA is a high-performance sine wave power inverter designed to provide clean, stable, and reliable AC power for industrial, commercial, and backup power applications. Engineered with advanced power conversion technology, it delivers fully isolated sinusoidal output voltage with low noise operation and enhanced protection features for safe and efficient performance. Built to meet international industrial safety standards, the Sollatek 300 VA inverter is ideal for sensitive electronic equipment, telecommunications systems, railway applications, and power backup installations.

Product Features

Pure Sine Wave Output

The inverter delivers a fully isolated clean sinusoidal output voltage, ensuring stable and reliable power suitable for sensitive electronic devices and industrial equipment.

Wide Input Voltage Range

Designed to operate within a broad input voltage range of 100V to 270V, the inverter provides dependable performance even under fluctuating power conditions.

High Energy Efficiency

With a minimum efficiency rating of 80% at full load, the inverter helps reduce energy loss while maintaining consistent power conversion performance.

Advanced Protection Features

The unit includes inrush current limiting, short-circuit protection, thermal shutdown with automatic reset, and output current limiting for improved operational safety and equipment protection.

Low Noise Filtered Design

Both the input and output are filtered for low electrical noise, meeting EN55022 Class A conducted and radiated emission requirements for enhanced system reliability.

Industrial and Railway Grade Build Quality

Manufactured to industrial and railway-quality standards, the inverter is designed for demanding environments and continuous operation.

Reliable Cooling System

The inverter uses natural convection cooling combined with conduction to chassis or heat-sink systems for efficient thermal management without excessive noise.

Product Specifications

• Brand: Sollatek
• Product Type: Power Inverter
• Power Capacity: 300 VA
• Input Voltage Range: 100V – 270V
• Output Voltage: 220V AC
• Frequency: 50Hz Input / 50Hz Output
• Output Waveform: Pure Sine Wave
• Efficiency: Minimum 80% at Full Load
• Operating Temperature Range: 0°C to +50°C
• Protection Features: Short-circuit protection, thermal shutdown, current limiting, and inrush current limiting
• Cooling Method: Natural Convection and Chassis Conduction Cooling
• Compliance Standards: UL 458, EN/UL60950-1, C22.2 No. 107.1-01
• Width: 17 cm
• Height: 21 cm
• Application: Industrial backup power, railway systems, telecommunications, and sensitive electronic equipment
