MikroTik SXTsq 5 ac 5GHz 16dBi Outdoor Wireless CPE/Backbone Bridge (RBSXTsqG-5acD)

The MikroTik SXTsq 5 ac (RBSXTsqG-5acD) is a compact, high-performance outdoor wireless device designed for point-to-point links and CPE applications. Operating on the 5GHz band with 802.11ac technology, it delivers fast and reliable wireless connectivity with data rates up to 867 Mbps. Featuring an integrated 16 dBi directional antenna and Gigabit Ethernet port, this device ensures optimal throughput for long-distance wireless bridging. Its lightweight, ultra-slim design makes installation simple, while the durable IP54-rated enclosure ensures reliable operation in harsh outdoor environments. Ideal for ISPs, enterprise backhaul, and outdoor networking deployments, the SXTsq 5 ac offers excellent performance at a cost-effective price point.

Product Features

High-Speed 5GHz Wireless AC

Supports 802.11a/n/ac standards with dual-chain technology, delivering up to 867 Mbps for fast and stable wireless links.

Integrated 16 dBi Directional Antenna

Built-in high-gain antenna ensures strong signal performance for long-distance point-to-point connections and CPE deployments.

Compact and Lightweight Design

Slim and space-efficient form factor, approximately twice as thin as previous models, allowing easy installation in tight or outdoor locations.

Gigabit Ethernet Port

Includes a 10/100/1000 Mbps Ethernet port to fully utilize high-speed wireless performance without bottlenecks.

Durable Outdoor Construction

IP54-rated enclosure protects against dust and splashes, ensuring reliable operation in extreme temperatures from -40°C to 70°C.

Efficient Passive PoE Powering

Powered via passive PoE (10–28 V), simplifying deployment in outdoor and remote installations.

Advanced RouterOS Features

Runs MikroTik RouterOS Level 3, enabling flexible configuration for bridging, routing, and wireless management.

Product Specifications

• Product Code: RBSXTsqG-5acD
• Architecture: ARM 32-bit
• CPU: IPQ-4018, 4 cores, 488–896 MHz
• CPU Threads: 4
• RAM: 256 MB
• Storage: 16 MB FLASH
• RouterOS License: Level 3
• Operating System: RouterOS
• Dimensions: 129 x 129 x 34 mm
• Tested Ambient Temperature: -40°C to 70°C
• MTBF: ~100,000 hours at 25°C
• Power Input: Passive PoE (10–28 V)
• Max Power Consumption: 7 W
• Cooling Type: Passive
• Wireless Standards: 802.11a/n/ac (Wi-Fi 5)
• Max Data Rate: 867 Mbps (5 GHz)
• Wireless Chains: 2
• Antenna Gain: 16 dBi
• Ethernet Ports: 1 x Gigabit Ethernet
• Certifications: CE, FCC, IC, EAC, ROHS
• IP Rating: IP54
